Mitsubishi FX3U-16MR-ES-A Logic Module – 8 Inputs, 8 Outputs, Computer, HMI Interface
Mitsubishi Electric Logic Module
The Mitsubishi FX3U series logic module has 8 inputs and 8 relay outputs with a contact rating of 8A. This DIN rail mount logic module has a screw termination method. It has a large memory for applications that require a large space. This logic module has a supply voltage that ranges between 100VAC and 240VAC.
Mitsubishi FX3U
FX3U CPU’s are compatible with existing FX2N expansion modules as well as the new FX3U ADP expansion modules and may be used as a replacement for FX2N PLC’s.
Features and Benefits
Expandable compact PLC
I/O,ADP & special function modules available
Exchangeable interface & I/O adapter boards
Operating temperature ranges between 0°C and 50°C
High processing speed
64K steps battery-backed RAM memory
249 applied instructions, 7680 auxiliary relays, 512 timers, 251 counters and40768 data registers
0.065μs/basic instruction
Backward compatibility
Password access protection
Manufacturer Series FX3U
Number of Inputs 8
Input Type Sink/Source
Output Type Relay
Number of Outputs 8
Program Capacity 64000 Steps
Programming Interface Computer, HMI
Width 90mm
Length 130mm
Depth 86mm
Minimum Operating Temperature 0°C
Mounting Type DIN Rail
Programming Language Used Ladder Logic
Output Current 8 A
Maximum Operating Temperature +50°C
Dimensions 130 x 90 x 86 mm
